A bi-directional and versatile Artnet to DMX512 converter
It converts ArtNet data from into 4 DMX512 signal outputs to control physical luminaires
Hardware Features
- Support Artnet I, II, III
- Consoles, desks, or controllers that are compatible with Art-Net to distribute Art-Net data via Ethernet network
- With the default profile, each DMX Port is mapped to it's respective Art-Net Universe
- 4x512 DMX Channel
- TVS Protection
- The cover logo and website logo can be customized
- Support web page to modify IP, Subnet and universe
- Support broadcast mode & unitcast mode
- Matching socket in all countries
- 110V, 220V international voltage is available
- Can be expanded to 1024x512Channels for 256PCS E16 work
- Universe : 4
- CPU : ARM
- Support Software : Madrix, Resolume, Arkaos, etc
- Input Protocols : Art-Net II, Art-Net III
- Configuration(Web Browser) : Ethernet IP Address, Node Name
- Output Protocol : DMX-512
- Input Connection : RJ45
- Output Connection : 5Pin/3Pin XLR
- Input Isolation : External Ethernet port Isolated to 2kV
- Output Interface Protection : TVS, PTC, DMX Output Ground Referenced, +15kV ESD DMX Driver Protection
- Input Voltage : DC 5V-24V
- Input Power (max) : 2W
- Overall Dimensions : 125x70x45MM
